Product Detials



FWX85

FWX85

The FWX85 is a robust and reliable metric hydraulic crawler crane engineered for heavy lifting and complex construction tasks.

Category: FUWA
Get a quote
  • Description
  • Specs
  • Technical Data
The FWX85 is a specialized hydraulic crawler crane developed for rigorous lifting and construction applications. Engineered with an advanced lattice boom system, it delivers outstanding reach and lifting capacity while maintaining operational stability. Built to adapt to versatile environments, the unit incorporates precise hoisting speeds and exceptional mobility. Its thoughtful transport dimensions and streamlined assembly process make it an invaluable asset for heavy-duty construction sites requiring dependable, high-capacity material handling.
Key Specifications: - Max boom length: 58 m m - Engine power: 194-209 kW @ 2000 rpm kW - Crane mass (basic): 77.8 t t
Max boom length: 58 m m Boom + fly jib length: 58 + 18 = 76 m m Boom hoist speed: 60 (rope dia. 18 mm) m/min Main hoist speed (low): 105 (rope dia. 22/26 mm) m/min Aux hoist speed (low): 105 m/min Travel speed: 1.5 km/h Single line pull: 8 t (S-type) / 20 t (MS-type) t Engine power: 194-209 kW @ 2000 rpm kW Transport dimensions: 11717 × 3500 × 3560 mm Crane mass (basic): 77.8 t t Boom luffing angle: 30-80 deg
